  1. Here's a very interesting video about the Audio Ltd 1010 system: https://vimeopro.com/ipstv/ips-tv-at-ibc-2015/video/138976610
  2. api

    Favorite Tools

    Tadah! Here's what I came up with. Thanks for the slip-n-snip scissors tip!
  3. I have been very happy with the ergonomics and sound quality of the DWX system. I'm using the sled adapter with XLR outs. 10 mw is often sufficient transmission power setting. The remote gain function is very handy, although there is minor clicking while you change gain on the fly. In practice this hasn't been a critical issue for me. I am using the bodypacks with DPA 4063, but they do work with DPA 4060 as well, I have noticed. Zaxcom as a brand isn't as mainstream here in Europe as it is in USA. The 50 mw cap on transmission power and the higher price of Lectros compared to USA are big considerations over here. My main reson for purchasing the system was to finally get a wireless boom solution that would provide a minimal compromise in sound quality.
  4. api

    Favorite Tools

    ​Thanks for the tip. Though cycling tools tend to have metric allen keys only? If there was one with 7/32 inch allen key and a 10 mm wrench it would be awesome. I'll look around a bit.
  5. api

    Favorite Tools

    For my travel kit I'm looking for a super light weight and minimal tool kit with the following tools Scissors 1/4 inch hex bit holder (or 7/32 inch allen key & wide slot head screwdriver) Adjustable wrench Here's what I've found so far as a "base" multi-tool that could perhaps be supplemented with a single extra piece of kit (most likely scissors?) http://www.amazon.com/Adjustable-Screwdriver-Spanner-Survival-Emergency/dp/B00Q6A4Q1W http://www.gerbergear.com/Hunting/Tools/Myth-Archery-Multi-Tool_31-002138 <- doesn't have the 7/32 inch allen key though http://www.crkt.com/guppie Any ideas on how to do this by buying a minimal amount of individual pieces of kit?
  6. The heavy fur works very well in rain too, I have noticed… as a sort of an umbrella to protect the inner structure and microphone itself from water. There appears to be no damage out of water exposure. Dry it out and you are good to go again.
  7. What is your squelch setting? Does it happen at all transmission power settings?
  8. Another issue that might be relevant regarding superslot and Sony DWX compatability: I am actually getting a metering anomaly when a Sony DWX receiver is connected via analog mic level XLR to my SD 664. It works without a hitch on transformer balanced inputs (MixPre-D for example). The anomaly is there even when both devices are powered via internal battery and using starquad cabling. AES3id -> AES3 connection to SD664 works fine though. Still waiting for a response to my email to SD technical support.
  9. Thanks for the tips, Tom. It is powered via a PagLink V-mount battery and Battery Bud II which is not a regulating BDS. I tried connecting the receiver to a MixPre-D (which has transformer-balanced inputs) and everything seemed to work.. no interference on meters. Then I tried powering the receiver via it's internal Sony L-battery and 664 via internal AA batteries. I disconnected the external power cable from 664 completely. The interference was still there. I wonder if this issue is somehow related: http://www.sounddevices.com/support/tech-notes/technical-bulletin-664-xlr-inputs-with-unbalanced-output-devices I am still unsure if the XLR outputs on the receiver are balanced or unbalanced. Although it's not listed in Sony's specs, this article gave me the impression that they are balanced after all: http://www.prosoundweb.com/article/sony_unveils_new_adaper_for_digital_wireless_systems/
  10. OK, now I've been able to conduct more tests with the DWX system and my SD 664. There is a really weird monitoring issue when using the analog mic level outs of the receiver. The meters are showing a high level of interference, but it's not audible while monitoring the ISO track. When I increase the mix level of that channel, a digital interference is audible on the L and R master tracks. The anomaly is present even when none of the other devices are on. The bag is powered via a Battery Buddy II BSD. However, the interference is not actually recorded! The recorded tracks are fine.. I've enclosed a short sample wav file. I thought that my 664 has been upgraded to fix the 80 khz unbalanced audio monitoring issue, so I I'm not sure if this is related to that or not. When using AES3id->AES3 connection between the mixer and the receiver there are no issues with metering or monitoring. I sent an e-mail to Sound Devices technical support e-mail address, but I haven't received a reply yet. dwx_clean_iso.wav
  11. api

    Nuendo 7

    One thing worth noting is that Nuendo has 5.1 support built-in, doesn't it? The price differnce between PT and PT HD is quite substantial.
  12. I recently purchased a used Sony DWX set including two body packs and a plug-on transmitter to complement my two Lectro SMDbs. I am confident that there will be no intermodulation issues between these two systems. Still waiting for DAD6008 adapters and I don't have DPA 4063's yet either, but I'll be able to post a full report later on. In the meantime, feel free to PM me. Sound quality on DWX is on par with Zaxcom, probably even better. For all practical purposes it is indistinguishable from a wired connection. Build quality is great, but battery holder is a bit flimsy. I bought spares just in case. Remote control including remote gain and re-freqing and sleep/unsleep works very well, a re-pairing proxedure is required when switching between bodypack and plug-on transmitter. Receiver adapter has AES out on a bnc connector and backup power on a L-series battery, btw. Interference resistance of the codec is very robust too, no dropouts whatsoever in my tests so far.
  13. api

    "True" 24 fps

    Just to clarify, I asked about this and I found out that it is not possible to conform the audio file from 23,976 to 24,000 on the fly while the DCP package is being projected. Changes to picture aspect ratio and playback volume are the only adjustments available at that stage… at least with their projector. So, as far as I understand it, the .1% pull-up during mastering is mandatory if the source material is 23,976 and the film is destined for 24,00 fps DCP projection. I am not sure if such a thing exists as 23,976 fps DCP projection.
  14. api

    "True" 24 fps

    A friend of mine (whose wife runs a neighbourhood art house film theatre) is operating a small scale DCP mastering service. A lot of his work is actually quality control and standards compliance monitoring. I am not 100% sure, but I am under the impression that audio and video files stay as separate file structures all the way to the actual playback and projection. If the video file is 23.98 instead of 24.00 and you want to play back the package at 24 fps, I think that the DCP server can be instructed to "auto-conform" the audio files on the fly by re-interpreting the audio at a different sample rate, if needed. Anyways, 24.00 fps is indeed a standards-compliant frame rate for DCP packages.. 23.98 fps is not. As Tuomas mentioned, 24.00 fps / 48 kHz is a tried and true workflow for theatrical release films here in Europe. As a side note, I had a strange 23.98/24.00 issue with a PIX240. Even if the PIX240 was set to 24.00 timecode (freerun), it would drop into 23.98 TC mode if the SDI signal from the camera dropped (during battery changes). Luckily I found out about the issue during tests before the actual shoot.
  15. Mark, which sync box were you using and what was the project frame rate?
  16. Below is the quote from Alkor Technologies. The antireflective coating on both sides adds 16 USD per piece to the price. Someone would have up with a way to securely attach in the the mixer as well. Delivery time is 6 weeks. The size of the window is specified as 40mm x 50mm just to give a ballpark idea for a consignment like this. ---------------------------------------------------------------- Protection sapphire window for LCD display 40x50x2 +/-0.1mm Uncoated 50pcs - 56USD/pc AR/AR coated with MgF2 coating for 400-700nm (visible) 50pcs - 72USD/pc ----------------------------------------------------------------
  17. I contacted Alkor and asked for a rough price estimate for this. 50 pieces of 2 mm thick sapphire windows with anti reflective coating in the visible spectrum. They are preparing the quote for tomorrow.
  18. I stumbled upon this russian company while trying to find a general price range of custom consignments like this. Minimum sum of their orders is 500 USD. Lead time 3-4 weeks for windows. Not sure if they can do AR coating or not. http://www.alkor.net/Sapphire/sapphire_windows_catalog.html
  19. Ahem, please let me rephrase my question: If there is no other timecode gear available for the production and a timecode cable between 240 and 664 is out of the question... How would you maintain timecode sync between these three devices while using 24P timebase on all three of them? I've come to the conclusion that the only feasible way to do this is to switch to 23.976 timebase. The final deliverables are a 24 FPS DCP file and a 25 FPS file for broadcast, so the issue will have to be dealt with in the post. It seems to me that working in 24P is just not worth all the trouble as you are likely to run into all sorts of unexpected hiccups like this during the production. Staying in 23.976 all the way to the end and time stretching the audio during mastering is way simpler and more reliable way to do it.
  20. I really am quite optimistic about this fan upgrade. The often overlooked issue with running the fan at 25% and waiting for it to kick in at 100% is that the noise on the CMOS sensor increases significantly as it heats up. This is especially evident when shooting in low light. Therefore, you only have two choices on long takes: either you increase the noise in your image or you increase the noise in your audio. If indeed after the fan upgrade the camera can run at 35% fan speed all the time without ever reaching overheat treshold, I think it's a huge improvement over the current situation.
  21. I am trying to find a way to work with true 24P timebase using SD664 as the sound recorder and a PIX240 mounted on a Scarlet-X to record 24P Quicktime proxy files. PIX240 is fed with a scratch track via a Lectrosonics SRb in a Ambient Vslot adapter. I am outputting 1080p24 genlock signal from PIX 240 to a RED Scarlet-X and timecode as well. Video File resolution rate on PIX 240 is set to 1080p24/23.976. Sync Out is set to 24P. Timecode is in Freerun mode. Project time base on the Scarlet is set to 24 and SDI output is set to 24hz. Everything works OK as long as the Scarlet-X powered up and feeds the PIX 240 with a 24hz SDI signal. However, the instant I turn the camera off and SDI output signal on the Scarlet-X disappears, PIX 240 switches to 23.976 timecode. I have verified that this is the case with the monitor function of the jam menu on 664. When I turn the camera back on, the timecode output on the PIX 240 reverts back to 24ND I am curious if there is a way to lock the timecode to 24P mode on the PIX240 even when there is no signal on the SDI input of the PIX240? Here is a video of the timecode generator behavior to illustrate what I mean: pix.MOV
  22. I've been searching high and low for 6 channel AES out via USB, but RMEs ADI-4 DD with Fireface UC is the only affordable solution I have found so far. As far as I know, for external audio interfaces on the Mac Metric Halo's LIO-8 is the next step up and it only does Firewire.
  23. For European folks, I can highly recommend products by Be-Ge from Sweden. They make driver seats for vehicles and special chairs for use in "24h" environments such as surveillance centers and air traffic control towers. I've had one for more than 20 years now and it has seen tens of thousands of hours of use. I've only had to replace the arm rests once and the wheels once. I've had zero issues with back pain or RSI symptoms even though I've always used a regular mouse and a keyboard. I think that this chair has literally saved me from burn out, not to speak of early retirement! And I agree, a chair has to fit like a shoe.. once you find a perfect one, you wonder how you ever managed without one like that. http://kob.be-ge.se/index.php?option=com_virtuemart&page=shop.browse&category_id=3&Itemid=120&TreeId=2
  24. I had a positive experience with https://bongous.com/ They are not cheap though, but if you consolidate multiple orders into a single shipment, it's not so bad.
  25. I have the Piano and I love it! I'm using it with a Sanken CS3e. It's super light and very durable too. I bought it in Paris from Areitec. Nowadays there is a rain cover available for it too: http://www.cinela.fr/catalog.php?language=en&pid=82
